Description
The 48V 200Ah LiFePO4 Battery is a high-performance lithium battery solution designed for commercial and industrial applications. As a leading lithium battery manufacturer, we specialize in OEM-ready designs, offering exceptional energy density, extended cycle life, and robust safety features. Ideal for electric vehicles and material handling equipment, this battery combines reliability with customizable options to meet diverse operational needs.
Key Features
High Capacity & Efficiency: Delivering 10.75kWh of energy, the 48V 200Ah lithium battery ensures extended runtime for demanding applications like electric forklifts and AGVs.
Advanced BMS Protection: Built-in smart BMS safeguards against overcharge, overheating, and voltage fluctuations, ensuring long-term safety.
IP67 Durability: Waterproof and dustproof construction guarantees reliable performance in harsh environments.
Flexible Configuration: Supports up to 4P4S connectivity and optional upgrades like self-heating, GPS tracking, or solar MPPT for specialized OEM requirements.
Product Description
Engineered with LiFePO4 (LFP) cells, this lithium battery delivers over 6,000 cycles at 80% depth of discharge, significantly outperforming traditional lead-acid alternatives. Its compact metal casing (750 ¡Á 330 ¡Á 273 mm) and lightweight design (79 kg) simplify integration into golf carts, floor scrubbers, and trolling motors. With a broad temperature range (-20¡ãC to 60¡ãC discharge) and rapid charging (180A max current), it maximizes uptime for commercial users.
Technical Excellence
The battery¡¯s peak discharge current of 200A (30 seconds) supports high-power demands, while RS485/CAN-bus communication enables seamless integration with fleet management systems. Optional Bluetooth or 4G connectivity provides real-time monitoring via mobile apps, making it a future-proof choice for smart OEM applications.
A 48V 200Ah LiFePO4 golf cart battery (short size) delivers high energy density, long cycle life, and robust safety features in a compact form factor. It offers reliable, efficient power for golf carts and electric vehicles, with fast charging, low maintenance, and a sophisticated Battery Management System (BMS) for optimal performance and durability.
What Are the Key Specifications of the 48V 200Ah LiFePO4 Golf Cart Battery (Short Size)?
The 48V 200Ah LiFePO4 golf cart battery provides a nominal voltage of 51.2V and a capacity of 200Ah, equating to approximately 10.24 kWh of energy. Its compact short-size design fits tight battery compartments, measuring roughly 520 x 270 x 220 mm and weighing about 25-30 kg, significantly lighter than lead-acid alternatives. The battery supports continuous discharge currents of up to 200A and peak bursts up to 400A. Equipped with a smart BMS, it offers protections against overcharge, over-discharge, short circuits, and temperature extremes. The battery operates efficiently between -5°C and 55°C and features an IP65 or higher rating for dust and water resistance.
| Specification | Detail |
|---|---|
| Nominal Voltage | 51.2V |
| Capacity | 200Ah |
| Energy | ~10.24 kWh |
| Dimensions (L×W×H) | ~520 x 270 x 220 mm |
| Weight | 25-30 kg |
| Continuous Discharge Current | 200A |
| Peak Discharge Current | 400A (short bursts) |
| Operating Temperature Range | -5°C to 55°C |
| Cycle Life | >6000 cycles (80% DOD) |
| Battery Management System | Integrated smart BMS |
| IP Rating | IP65+ |
How Does the Short Size 48V 200Ah LiFePO4 Battery Improve Golf Cart Performance?
The compact design allows easy retrofitting into golf carts with limited battery space without sacrificing capacity or power. Its high energy density extends run times and reduces weight, improving acceleration and handling. The advanced BMS optimizes battery health, ensuring consistent power delivery and safety during operation. Fast charging capabilities minimize downtime, enabling longer usage periods.
What Safety Features Does the 48V 200Ah LiFePO4 Golf Cart Battery Include?
Safety is ensured through:
-
Advanced BMS: Monitors voltage, current, temperature, and state of charge to prevent overcharge, over-discharge, short circuits, and overheating.
-
Thermal Stability: LiFePO4 chemistry reduces risk of thermal runaway.
-
Robust Enclosure: IP65 or higher rated for dust and water resistance.
-
Cell Balancing: Maintains uniform charge across cells to extend battery life.
-
Overcurrent and Short Circuit Protection: Safeguards battery and connected equipment.
These features make it reliable and safe for demanding golf cart applications.
How Should the 48V 200Ah LiFePO4 Battery Be Charged and Maintained?
Charging requires a compatible LiFePO4 charger with a bulk voltage around 58.4V and maximum current typically 50-100A. Charging time ranges from 4 to 6 hours depending on charger specs. Maintenance is minimal—regular terminal cleaning, avoiding deep discharges below recommended voltage, and monitoring battery health via BMS or connected devices. Proper storage in moderate temperatures extends battery life.
Which Golf Cart Models Are Compatible with This Short Size Battery?
This battery fits many popular golf cart models including Club Car, EZGO, Yamaha, and others that require a 48V system with space constraints. Its compact size and standard terminal configurations facilitate easy upgrades or replacements in OEM and aftermarket applications.
What Are the Environmental Benefits of Using a 48V 200Ah LiFePO4 Golf Cart Battery?
LiFePO4 batteries offer:
-
Longer Lifespan: Reduces waste and replacement frequency.
-
Non-toxic Materials: No lead, cadmium, or harmful acids.
-
High Energy Efficiency: Low self-discharge and efficient charging.
-
Recyclability: Easier and safer to recycle than lead-acid batteries.
-
No Acid Spills or Emissions: Safer for users and the environment.
These benefits support sustainable and eco-friendly vehicle operation.
How Does Heated Battery Enhance the 48V 200Ah LiFePO4 Golf Cart Battery Experience?
Heated Battery integrates advanced BMS technology with optional heating elements to maintain optimal battery temperature in cold climates, preventing capacity loss and performance degradation. Their batteries feature rugged IP65+ rated enclosures and real-time monitoring via Bluetooth or CANBus, ensuring reliable power and extended battery life even in harsh environments.
What Are the Cost Advantages of Choosing a 48V 200Ah LiFePO4 Battery?
Though the upfront cost is higher than lead-acid batteries, total cost of ownership is lower due to:
-
Extended cycle life exceeding 6000 cycles.
-
Minimal maintenance and no watering.
-
Faster charging reducing downtime.
-
Energy savings from higher efficiency.
-
Reduced environmental and disposal costs.
Choosing trusted brands like Heated Battery ensures warranty support and long-term reliability.
Heated Battery Expert Views
The 48V 200Ah LiFePO4 golf cart battery (short size) combines compact design with high capacity, delivering reliable, efficient power for golf carts and electric vehicles. Heated Battery’s integration of heating technology and intelligent BMS enhances cold-weather performance and safety, reducing downtime and maintenance costs. This battery is an excellent choice for users seeking durable, eco-friendly, and high-performance energy solutions.
— Senior Battery Engineer, Heated Battery
