Description
The 48V 150Ah LiFePO4 Battery is a high-performance lithium battery solution designed for demanding commercial and industrial applications. Built with LiFePO4 chemistry, it delivers 7.2kWh of energy, 6000+ cycles, and rugged durability. Ideal for OEM integrations and wholesale buyers seeking reliable, scalable power for electric vehicles and equipment.
Key Features
High-Performance LiFePO4 Cells: Ensures safety, thermal stability, and longevity even under extreme conditions.
7.2kWh Energy Output: Supports high-power applications like forklifts, AGVs, and electric rickshaws.
Smart BMS Protection: Guards against overcharge, overheating, and voltage fluctuations.
200A Continuous Discharge: Powers heavy-duty equipment with minimal voltage drop.
IP67 Rating & Metal Housing: Resists dust, water, and mechanical stress for outdoor/industrial use.
Flexible Configurations: Supports up to 4S4P connections for custom voltage and capacity needs.
Product Description
As a leading lithium battery manufacturer, we engineered the 48V 150Ah Battery for versatility across golf carts, floor scrubbers, trolling motors, and more. Its compact design and lightweight 55kg frame optimize space efficiency, while optional upgrades like self-heating, GPS, or solar MPPT enhance functionality. With a 20-year design life and 5-year warranty, this battery meets rigorous OEM requirements for reliability and ROI.
A 48V 150Ah LiFePO4 golf cart battery combines high energy density, long cycle life, and advanced safety features to deliver reliable, maintenance-free power. With fast charging, lightweight design, and smart Battery Management System (BMS), it outperforms traditional lead-acid batteries, offering extended runtime and enhanced performance for golf carts and electric vehicles.
How Does a 48V 150Ah LiFePO4 Golf Cart Battery Work?
The 48V 150Ah LiFePO4 battery consists of lithium iron phosphate cells arranged in series and parallel to provide a nominal voltage of 48 volts and a capacity of 150 ampere-hours. LiFePO4 chemistry offers a flat discharge curve, maintaining stable voltage throughout most of the discharge cycle. An integrated BMS monitors voltage, current, temperature, and state of charge to protect against overcharging, deep discharging, short circuits, and overheating, ensuring safety and maximizing battery lifespan.
What Are the Key Benefits of Using a 48V 150Ah LiFePO4 Battery in Golf Carts?
-
High Energy Capacity: Approximately 7.2 kWh of usable energy for extended driving range.
-
Long Cycle Life: Over 4000 cycles at 80% depth of discharge, significantly reducing replacement frequency.
-
Lightweight Design: Weighs around 60 kg, about 50% lighter than equivalent lead-acid batteries.
-
Fast Charging: Supports charging currents up to 75A, enabling full recharge in 6-7 hours.
-
Robust Safety Features: Fireproof, shockproof, and IP67 waterproof casing with advanced BMS protection.
-
Wide Operating Temperature Range: Functions reliably between -20°C and 60°C.
-
Maintenance-Free: No watering or equalizing required.
-
Smart Monitoring: Optional Bluetooth and LCD touchscreen for real-time battery status.
Which Vehicles and Applications Are Best Suited for a 48V 150Ah LiFePO4 Battery?
Ideal for:
-
Golf carts and utility vehicles.
-
Low-speed electric vehicles (LSVs).
-
Electric scooters and tricycles.
-
Solar energy storage and backup power.
-
Marine and recreational vehicles.
Its versatility and high capacity support a broad range of electric mobility and energy storage needs.
Why Is the Battery Management System (BMS) Critical for This Battery?
The BMS ensures safe and efficient operation by continuously monitoring individual cell voltages, temperature, and current. It prevents overcharging, deep discharging, overheating, and short circuits. The BMS also balances cells during charging to maximize capacity and extend battery life.
How Long Does It Take to Charge a 48V 150Ah LiFePO4 Golf Cart Battery?
Charging time depends on charger current:
| Charger Current | Approximate Charging Time | Notes |
|---|---|---|
| 30A | 6-7 hours | Standard charging rate |
| 75A | 3-4 hours | Fast charging, requires compatible charger |
| Lead-Acid | 10-12 hours | For comparison |
Using a charger designed for LiFePO4 chemistry is essential to protect battery health.
What Are the Technical Specifications of a Typical 48V 150Ah LiFePO4 Battery?
| Specification | Value |
|---|---|
| Nominal Voltage | 48 V |
| Nominal Capacity | 150 Ah |
| Nominal Energy | 7.2 kWh |
| Max Charge Voltage | 54.75 V |
| Discharge Cut-off Voltage | 37.5 V |
| Max Continuous Charge Current | 75 A |
| Max Continuous Discharge Current | 150 A |
| Peak Discharge Current | 300 A (1-3 seconds) |
| Dimensions (L x W x H) | Approx. 650 x 520 x 180 mm |
| Weight | ~60 kg |
| Cycle Life | >4000 cycles |
| Self-Discharge Rate | ~2% per month |
| Operating Temperature | -20°C to 60°C |
| Protection Class | IP65 |
Can a 48V 150Ah LiFePO4 Battery Replace Lead-Acid Batteries in Golf Carts?
Yes. LiFePO4 batteries offer longer lifespan, lighter weight, faster charging, and require less maintenance. They provide more consistent voltage and improved safety compared to lead-acid batteries.
| Feature | Lead-Acid Battery | LiFePO4 Battery |
|---|---|---|
| Cycle Life | 300–500 cycles | >4000 cycles |
| Weight | Heavier | ~50% lighter |
| Charging Time | 10–12 hours | 3–7 hours |
| Maintenance | High | Low |
| Safety | Acid leakage risk | Thermally stable |
Where Can You Purchase Reliable 48V 150Ah LiFePO4 Golf Cart Batteries?
Heated Battery offers premium 48V 150Ah LiFePO4 golf cart batteries featuring advanced BMS, durable construction, and smart monitoring options. Available through authorized distributors and online retailers, Heated Battery products come with warranties and expert support.
How Does Temperature Affect the Performance of a 48V 150Ah LiFePO4 Battery?
Performance is optimal between 0°C and 60°C. Capacity and discharge rates decrease at low temperatures but remain superior to lead-acid alternatives. Heated Battery models may include thermal management to maintain performance in cold climates.
What Environmental Benefits Do LiFePO4 Batteries Provide?
LiFePO4 batteries use non-toxic materials, have longer service lives reducing waste, and are recyclable. Their higher efficiency reduces energy consumption, supporting sustainable energy solutions.
How Does Cell Balancing Improve Battery Performance?
Cell balancing ensures all cells maintain uniform voltage and capacity, preventing weak cells from limiting overall performance. This extends battery life, improves safety, and maintains consistent power output.
Heated Battery Expert Views
The 48V 150Ah LiFePO4 golf cart battery represents a leap forward in electric mobility power solutions. At Heated Battery, our focus is on integrating intelligent BMS and thermal management to ensure safe, reliable, and long-lasting performance. Our batteries provide extended run times, rapid charging, and minimal maintenance, making them a cost-effective and environmentally responsible choice for golf cart users worldwide. — Senior Battery Engineer, Heated Battery
How Does the Cycle Life of a 48V 150Ah LiFePO4 Battery Compare to Other Batteries?
LiFePO4 batteries typically offer 8 to 12 times the cycle life of lead-acid batteries, ranging from 4000 to 6000 cycles, significantly reducing replacement frequency and costs.
What Maintenance Is Required for a 48V 150Ah LiFePO4 Golf Cart Battery?
Minimal maintenance includes:
-
Using compatible LiFePO4 chargers.
-
Avoiding deep discharges below cutoff voltage.
-
Storing in a cool, dry place.
-
Periodically inspecting connections and cleaning terminals.
When Should You Replace Your 48V 150Ah LiFePO4 Battery?
Replace when capacity drops below 70-80% of original rating or when runtime and charging efficiency degrade significantly. Regular capacity testing helps monitor battery health.
What Custom Features Can Enhance 48V 150Ah LiFePO4 Battery Usage?
Custom options include Bluetooth monitoring, CAN-bus communication, self-heating, GPS tracking, and tailored form factors to fit unique golf cart designs, improving user experience and operational efficiency.
