Description
Our 25.6V 150Ah LiFePO4 Battery combines cutting-edge lithium technology with robust OEM customization options, designed for high-performance applications. Built with LiFePO4 cells, this battery delivers 3840Wh of energy, IP65 protection, and a 10-year design life. Ideal for commercial and industrial use, it supports up to 6 parallel connections and offers optional upgrades like self-heating, Bluetooth, and solar MPPT.
Key Features
– Advanced LiFePO4 Chemistry: Ensures safety, thermal stability, and over 5000 cycles at 80% DOD.
– High Energy Density: 3840Wh capacity in a compact, BCI Group 8D-compatible design (523x269x218mm).
– Rugged Construction: ABS shell with IP65 rating for dust/water resistance.
– Wide Temperature Range: Operates from -20¡ãC to 65¡ãC (discharge) and 0¡ãC to 60¡ãC (charge).
– Smart Integration: Optional DALY/JBD BMS, 4G/GPS, and LCD displays for real-time monitoring.
Product Description
As a leading lithium battery manufacturer, we specialize in high-efficiency solutions like the 25.6V 150Ah LiFePO4 Battery, engineered for reliability in demanding environments. With a 100A continuous charge/discharge current and M8 terminals, it powers heavy-duty equipment, renewable energy systems, and EV applications. The 3% monthly self-discharge rate and UL/IEC/CE certifications ensure compliance and longevity. Custom OEM services include branding, silkscreen logos, and tailored upgrades like cooling fans or active balancing.
A 24V 150Ah LiFePO4 battery offers high energy density, long cycle life, and enhanced safety, making it perfect for solar power systems, electric vehicles, and backup applications. Its lightweight design, fast charging, and integrated Battery Management System (BMS) ensure reliable, maintenance-free operation, outperforming traditional lead-acid batteries in efficiency and durability.
How Does a 24V 150Ah LiFePO4 Battery Work?
A 24V 150Ah LiFePO4 battery consists of lithium iron phosphate cells connected in series and parallel to provide a nominal voltage of 25.6 volts and a capacity of 150 ampere-hours. The LiFePO4 chemistry delivers a flat discharge curve, maintaining stable voltage throughout most of the discharge cycle. An advanced BMS monitors cell voltages, temperature, and current to prevent overcharge, over-discharge, and short circuits, ensuring safety and extending battery lifespan.
What Are the Key Benefits of Using a 24V 150Ah LiFePO4 Battery?
-
Long Cycle Life: Typically over 3000 to 6000 cycles at 80% depth of discharge.
-
Lightweight: Approximately 28-30 kg, significantly lighter than equivalent lead-acid batteries.
-
Stable Voltage Output: Ensures consistent power delivery for sensitive electronics.
-
Fast Charging: Supports charging currents up to 70-80A, reducing downtime.
-
Low Self-Discharge: Retains charge efficiently during storage.
-
Enhanced Safety: Thermally stable chemistry with multiple protection features.
-
Maintenance-Free: No watering or equalizing required.
-
Smart Monitoring: Optional Bluetooth, CAN-bus, or RS485 communication for real-time status.
Which Applications Are Best Suited for a 24V 150Ah LiFePO4 Battery?
This battery is ideal for:
-
Solar energy storage and off-grid systems.
-
Electric vehicles, including golf carts and scooters.
-
Backup power for homes, telecom, and industrial equipment.
-
Marine and recreational vehicles.
-
Medical equipment and remote monitoring systems.
Its balance of voltage and capacity supports moderate to high energy demands.
Why Is a Battery Management System (BMS) Important?
The BMS protects the battery by continuously monitoring individual cell voltages, temperature, and current. It prevents overcharging, deep discharging, overheating, and short circuits. The BMS also balances cells during charging to maximize capacity and extend battery life.
How Long Does It Take to Charge a 24V 150Ah LiFePO4 Battery?
Charging time depends on charger current:
| Charger Current | Approximate Charging Time | Notes |
|---|---|---|
| 30A | 5-6 hours | Standard charging rate |
| 70A | 2-3 hours | Fast charging, requires compatible charger |
| Lead-Acid | 10-12 hours | For comparison |
Using a charger designed for LiFePO4 chemistry is essential for safety and efficiency.
What Are the Technical Specifications of a Typical 24V 150Ah LiFePO4 Battery?
| Specification | Value |
|---|---|
| Nominal Voltage | 25.6 V |
| Nominal Capacity | 150 Ah |
| Nominal Energy | 3.84 kWh |
| Max Charge Voltage | 29.2 V |
| Discharge Cut-off Voltage | 20 V |
| Max Continuous Charge Current | 75 A |
| Max Continuous Discharge Current | 150 A |
| Peak Discharge Current | 200 A (1-3 seconds) |
| Dimensions (L x W x H) | Approx. 483 x 170 x 240 mm |
| Weight | ~28-30 kg |
| Cycle Life | 3000-6000 cycles |
| Self-Discharge Rate | ~2% per month |
| Operating Temperature | Charge: 0°C to 45°C; Discharge: -20°C to 60°C |
| Protection Class | IP65 |
Can a 24V 150Ah LiFePO4 Battery Replace Lead-Acid Batteries?
Yes. LiFePO4 batteries offer longer lifespan, lighter weight, faster charging, and require less maintenance. They provide more consistent voltage and improved safety compared to lead-acid batteries.
| Feature | Lead-Acid Battery | LiFePO4 Battery |
|---|---|---|
| Cycle Life | 300–500 cycles | 3000–6000 cycles |
| Weight | Heavier | ~50% lighter |
| Charging Time | 10–12 hours | 2–6 hours |
| Maintenance | High | Low |
| Safety | Acid leakage risk | Thermally stable |
Where Can You Purchase High-Quality 24V 150Ah LiFePO4 Batteries?
Heated Battery offers premium 24V 150Ah LiFePO4 batteries with advanced BMS, durable construction, and smart monitoring options. Available through authorized distributors and online retailers, Heated Battery products come with warranties and expert support.
How Does Temperature Affect the Performance of a 24V 150Ah LiFePO4 Battery?
Performance is optimal between 0°C and 45°C. Capacity and discharge rates decrease at low temperatures but remain better than lead-acid alternatives. Heated Battery models may include thermal management to maintain performance in cold climates.
What Environmental Benefits Do LiFePO4 Batteries Provide?
LiFePO4 batteries use non-toxic materials, have longer service lives reducing waste, and are recyclable. Their higher efficiency reduces energy consumption, supporting sustainable energy solutions.
How Does Cell Balancing Improve Battery Performance?
Cell balancing ensures all cells charge and discharge evenly, preventing weak cells from limiting overall capacity. This extends battery life, maintains consistent voltage, and improves safety.
Heated Battery Expert Views
The 24V 150Ah LiFePO4 battery is a reliable and efficient energy storage solution. At Heated Battery, we integrate advanced BMS technology and robust safety features to deliver long-lasting, maintenance-free performance. Our batteries are engineered for diverse applications, from solar systems to electric vehicles, providing efficient, safe, and environmentally friendly power. We prioritize quality and customer support to meet evolving energy needs. — Senior Battery Engineer, Heated Battery
